Description

Meet the Pioneer Diamante Mini Split System to cool and heat three different rooms. You’ll be sent:  36,000 BTU Multi-Zone Condenser, three 12,000 BTU Wall Mounted Air Handler, three Remotes, and three 33 ft. Installation Kits.

System Includes

• Pioneer® Diamante Ultra Series 21.5 SEER Quad Zone Condenser, YN040GLFI22M4D
• Pioneer® 12,000 BTU Diamante Ultra 23 SEER Ductless Air Handler, WT012GLFI22HLD-25 (x3)
• Pioneer 33 ft. Lineset for Diamante 9K and 12K Indoor Unit, WYT-0912-33 (x3)

Condenser

• Energy Efficient. This 4 Zone condenser, when paired with select Pioneer air handlers, is capable of producing up to an impressive 21.5 SEER efficiency rating.
• Works In All Environments. The ability to heat even when temperatures drop to -4°F and cool up to 122°F
• Iron-Clad Warranty. For added peace of mind, this condenser comes with a 5 Year Warranty. Simply register within 90 days and you’ll be covered!

Air Handler, 12K BTU, Quantity 3

• Large Coverage Area. Handler covers an area of up to 450 sq. ft
• Versatile. Incredibly versatile and equipped with multiple operating modes, which include COOL, HEAT, TURBO, ECO and SLEEP.
• Convenient Installation. With its light and compact design, it can be installed easily to most interior walls with the included mounting plate.

Line Set 33 ft., Quantity 3

• This 33 ft. copper line set connects the Pioneer Diamante Series Condenser to the 9K and 12K Air Handlers.

What’s Not Included and Required for Installation

• Electrical Requirements, such as Disconnect Box or Electrical Whip
• Vacuum Pump or Vacuum Set (alternatively, you can use the Pioneer Flush Kit)

• Condenser
• Product Dimensions: 39 1/4″W x 15 5/8″D x 35 1/2″H
• Cooling Capacity: 32,000 BTU
• Heating Capacity: 35,000 BTU
• Zone Capacity: 4
• SEER: 21.5
• Outdoor Ambient Range (Cool): 5°F~122°F
• Outdoor Ambient Range (Heat): -4°F~86F
• Voltage: Requires a minimum of 208V-230V/60HZ/15A (double-pole) (please check your home meets this electrical requirement prior to purchase)
• Air Handler
• Product Dimensions: 36 1/4″W x 7 5/8″D x 12″H
• Mount Type: Wall
• Cooling Capacity: 12,000 BTU
• Heating Capacity: 12,000 BTU
• Square Footage Coverage: 450 Square Feet
• Line Set
• Length: 33 Feet
