Description

• SYSTEM OVERVIEW
• System Type: Ductless Mini Split Air Conditioner & Heat Pump
• Zones: 5
• Capacity: Total: 48,000 BTU//Zone 1: 9,000 BTU//Zone 2: 9,000 BTU//Zone 3: 9,000 BTU//Zone 4: 9,000 BTU//Zone 5: 12,000 BTU
• Coverage Area: Total: 1,900 sq. ft.//Zone 1: 350 sq. ft.//Zone 2: 350 sq. ft.//Zone 3: 350 sq. ft//Zone 4: 350 sq. ft//Zone 5: 500 sq. ft
• Refrigerant: R-454B
• Line Sets Included: None – Choose Your Line Sets Above!
• Warranty: 7 Years Compressor//5 Years Parts
• OUTDOOR UNIT (55K) x 1
• Model: DIY-MULTI6-55HP230D-O
• Dimensions: 37.48″ W x 16.34″ D x 52.48″ H
• Cooling Capacity: 47,000 BTU
• SEER2: 22.0
• EER2: 12.0
• Heating Capacity: 55,000 BTU
• HSPF2-4: 10.6
• HSPF2-5: 8.5
• Outdoor Noise Level: 64.0 dB(A)
• Outdoor Operating Temperature: Cooling: -22°F – 122°F//Heating: -22°F – 75°F
• Voltage: 208–230V
• Phase: 1
• Cycle: 60Hz
• Min Circuit Ampacity: 43.0A
• Max Fuse Breaker: 45.0A
• Weight: 245.81 lbs
• Certifications: ENERGY STAR Certified//AHRI Certified//UL Listed//ETL Listed
• INDOOR UNIT (9K) x 4
• Model: DIY-09-HP-WMAH-230D25-O
• Dimensions: 31.57″ W x 7.44″ D x 11.69″ H
• Mounting Type: Wall
• Cooling Capacity: 9,000 BTU
• Heating Capacity: 9,000 BTU
• Coverage Area: 151 to 350 sq. ft.
• Liquid Line Size: 1/4″
• Suction Line Size: 3/8″
• Modes: Auto Mode: Automatically selects heating or cooling based on the room’s temperature.//Cool Mode: Lowers the room temperature to your desired setting.//Heat Mode: Raises the room temperature to your desired setting.//Fan-Only Mode: Circulates air without heating or cooling.//Dry Mode (Dehumidification): Reduces humidity levels in the room.//Sleep Mode: Gradually adjusts temperature settings for comfortable sleep and energy savings.
• Weight: 24.47 lbs
• INDOOR UNIT (12K) x 1
• Model: DIY-12-HP-WMAH-230D25-O
• Dimensions: 31.57″ W x 7.44″ D x 11.69″ H
• Mounting Type: Wall
• Cooling Capacity: 12,000 BTU
• Heating Capacity: 12,000 BTU
• Coverage Area: 351 to 500 sq. ft.
• Liquid Line Size: 1/4″
• Suction Line Size: 3/8″
• Modes: Auto Mode: Automatically selects heating or cooling based on the room’s temperature.//Cool Mode: Lowers the room temperature to your desired setting.//Heat Mode: Raises the room temperature to your desired setting.//Fan-Only Mode: Circulates air without heating or cooling.//Dry Mode (Dehumidification): Reduces humidity levels in the room.//Sleep Mode: Gradually adjusts temperature settings for comfortable sleep and energy savings.
• Weight: 24.47 lbs
