Description

• SYSTEM OVERVIEW
• System Type: Ductless Mini Split Air Conditioner & Heat Pump
• Zones: 5
• Capacity: Total: 30,000 BTU//Zone 1: 6,000 BTU//Zone 2: 6,000 BTU//Zone 3: 6,000 BTU//Zone 4: 6,000 BTU//Zone 5: 6,000 BTU
• Coverage Area: Total: 750 sq. ft.//Zone 1: 150 sq. ft.//Zone 2: 150 sq. ft.//Zone 3: 150 sq. ft.//Zone 4: 150 sq. ft.//Zone 5: 150 sq. ft.
• Refrigerant: R-454B
• Line Sets Included: None – Choose Your Line Sets Above!
• Warranty: 7 Years Compressor//5 Years Parts
• OUTDOOR UNIT (36K) x 1
• Model: DIY-MULTI5-36HP230D-O
• Dimensions: 37.24″ W x 16.14″ D x 31.89″ H
• Cooling Capacity: 34,000 BTU
• SEER2: 23.0
• EER2: 12.0
• Heating Capacity: 36,000 BTU
• HSPF2-4: 9.9
• HSPF2-5: 7.5
• Outdoor Noise Level: 64.0 dB(A)
• Outdoor Operating Temperature: Cooling: -13°F – 122°F//Heating: -13°F – 75°F
• Voltage: 208–230V
• Phase: 1
• Cycle: 60Hz
• Min Circuit Ampacity: 30.5A
• Max Fuse Breaker: 35.0A
• Weight: 169.75 lbs
• Certifications: ENERGY STAR Certified//AHRI Certified//UL Listed//ETL Listed
• INDOOR UNIT (6K) x 5
• Model: DIYCASSETTE06HP-230D25-O
• Dimensions: 50.31″ W x 13.19″ D x 8.98″ H
• Mounting Type: Ceiling
• Cooling Capacity: 6,000 BTU
• Heating Capacity: 6,000 BTU
• Coverage Area: 100 to 150 sq. ft.
• Liquid Line Size: 1/4″
• Suction Line Size: 3/8″
• Airflow Direction: 1-Way
• Modes: Auto Mode: Automatically selects heating or cooling based on the room’s temperature.//Cool Mode: Lowers the room temperature to your desired setting.//Heat Mode: Raises the room temperature to your desired setting.//Fan-Only Mode: Circulates air without heating or cooling.//Dry Mode (Dehumidification): Reduces humidity levels in the room.//Sleep Mode: Gradually adjusts temperature settings for comfortable sleep and energy savings.
• Weight: 45 lbs
